Egis Triple Battery Advanced Automatic Charging Relay (ACR) - 24V [7612-24]

SKU: 114181
(0)
$173.99
-6% $185.50 $173.99
Only 4 left
Low inventory - Hurry up!
Ask an expert!

Not sure it fits? Send us your part number and we'll check. Call 310‑726‑3339 or email us.

Got questions?

For engine parts which show "IN STOCK" & "On backorder" They are available for transfer. 2-3 Week Lead time.

We advise you get in touch

Triple Battery Advanced Automatic Charging Relay (ACR) - 24V

Two Independent ACRs in One Device reduce installation space and time. Significantly lowers the out-of-state current draw.

Features:

  • Eliminates Dead Start Batteries by sharing charge sources with all batteries and isolating batteries when no charge sources are present
  • Simple & Robust Installation: Integrated sealed plug eliminates corrosion, includes DT04 harness. A single device reduces installation time, space, cost, and points of potential failure
  • An additional low-amp output can be used to report device status remotely.
  • Bullet-proof Construction: Sealed unit, high-temperature materials allow mounting anywhere. Integrated thermal overload shutdown protection
  • Ultra Low Off-State Current: Compare two typical ACRs (20 mA) vs Dual ACR @ 1.3 mA
  • Adjustable Off-Voltage for Auxiliary Battery Priority provides the ability to share start battery energy for auxiliary without risking engine starting ability.
  • Start/Engine Isolation input option for ensuring sensitive electronics do not experience voltage sags and spikes from the cranking event.
  • Start Assist input option to ensure maximum cranking amps available when necessary.
  • 4 Year Industry-Leading Warranty
This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:

  • Type: Electric
  • Box Dimensions: 3"H x 6"W x 7"L WT: 0.9 lbs
  • UPC: 850035199954

Brochure (pdf)
